Pneumatic Actuated Butterfly Valves, API 609, A351 CF8, 2 IN

Key Specifications / Features

The Pneumatic Actuated Butterfly Valves Factory offers high-performance valves designed to API 609 standards. These valves feature a concentric design with a stainless steel body (ASTM A351 CF8) and are available in DN50 (2 inch) size with a pressure rating of PN16 (Class 150 LB). Equipped with wafer ends for easy installation, these valves provide reliable flow control.

The Wafer Concentric Butterfly Valve is designed to ensure a bi-directional pressure seal, preventing backflow in unidirectional flow systems. It achieves this through a precision-machined valve face, tightly fitting seal, gasket, and o-ring. The valve body features threaded inserts on both sides, allowing installation with two sets of bolts without nuts. Positioned between two flanges, each side is secured with a separate bolt set, enabling one side of the piping system to be disconnected without disturbing the other.

Technical Specifications

» Size Range: 2-48 Inch (DN50-DN1200)
» Pressure Ratings: Class 150 LB, PN10, PN16
» Materials: GG25, GGG40, ASTM A216 WCB, A351 CF8, CF8M, CF3, CF3M
» Optional Seat Materials: Resilient NBR, EPDM, VITON
» Operation: Handle, Handwheel, Pneumatic, Electric
» End Connections: Wafer, Lug, RF Flange
» Design and Manufacture Standards: GB/T 12228, API 609
» Face-to-Face (End-to-End) Standard: GB/T 12221
» Flanged Connection Standards: ANSI B16.5, GB/T 9113
» Test and Inspection Standards: API 598, GB/T 13927
» Temperature Range: -29°C to 120°C
» Medium: Water, Gas, Oil, etc.
